Device turns plastic waste into chemicals for fuels

Researchers at Yale University have developed a method to convert plastic waste into fuels and other valuable products efficiently and cheaply using pyrolysis, a process that breaks down materials without oxygen.
The new method uses a 3D-printed electrically heated carbon column reactor with a hierarchical porous structure to control the reaction progress of chemicals, achieving a record-high yield of nearly 66% of plastic waste converted into usable products.
Conventional pyrolysis methods often rely on catalysts, which are expensive and have limited lifetimes, but this new method is catalyst-free, making it more cost-effective and sustainable.
The researchers tested the system using a sample of common plastic (polyethylene) and found that it converted over 56% of the plastic into useful chemicals, even when using a commercially available carbon felt design.

A plastic bottle floats in water.

As tons of plastic waste continue to build up in landfills every day, researchers have developed a way to convert this waste into fuels and other valuable products efficiently and cheaply.

Specifically, the researchers are using a method known as pyrolysis, a process of using heat in the absence of oxygen to molecularly break materials down. In this case, it’s used to break plastics down to the components that produce fuels and other products.

The study was led by Yale Engineering professors Liangbing Hu and Shu Hu, both members of the Center for Materials Innovation and Yale Energy Sciences Institute.

Conventional methods of pyrolysis often use a catalyst to speed up the chemical reactions and achieve a high yield, but it’s a method that comes with significant limitations.

“Whenever you talk about catalysts, they’re very expensive and you have a lifetime issue because catalysts will eventually die by different means,” says Liangbing Hu, a professor of electrical and computer engineering and materials science at Yale University, and director of Center for Materials Innovation.

Methods that don’t employ a catalyst, though, tend to have low rates of converting the waste into products of use.

For this project, the researchers found a way around both of these obstacles and developed a highly selective, energy-efficient, and catalyst-free pyrolysis method that can convert plastic into valuable chemicals.

The key, they say, is a 3D-printed electrically heated carbon column reactor made of three sections of decreasing pore size. The first section is made of one-millimeter pores, while the next section contains 500-micrometer pores, and the third section is made of 200-nanometer pores. As the chemicals pass through the reactor, the hierarchical porous structure plays a pivotal role in controlling the reaction progress of the chemicals.

For one thing, it prevents larger molecules from advancing through the reactor before they’ve been adequately broken down.

Further, it provides a way to control the temperature in the reactor, which prevents coking and other effects that can inhibit the process.

To test the system, the researchers tried the reactor out on a sample of common plastic known as polyethylene. The results are impressive: They report a record-high yield of nearly 66% of the plastic waste converted into chemicals that can be used for fuels.

Using 3D printing to build the structure allowed the researchers to precisely control the dimensions of the reactor pores and investigate the effects of pyrolysis.

To demonstrate a more scalable design, the researchers also used a device made up of commercially available carbon felt. They found that this design—even without the optimization that a 3D-printed structure provided—still improved the selectivity of the pyrolysis products and achieved a satisfactory yield, converting more than 56% of the plastic into useful chemicals.

“These results are very promising and show a great potential for putting this system into real-world application and offering a practical strategy for converting plastic waste into valuable materials,” says Shu Hu, assistant professor of chemical and environmental engineering.

The results of this work appear in Nature Chemical Engineering.

Additional collaborators are from Purdue University, the University of Delaware, Missouri University of Science and Technology, West Virginia University, the University of Wisconsin–Madison, Princeton University, and National Renewable Energy Laboratory and BOTTLE Consortium.

Source: Yale

The post Device turns plastic waste into chemicals for fuels appeared first on Futurity.

link

Q. What is the method used by researchers to convert plastic waste into fuels and other valuable products?

A. The method used is pyrolysis, a process that uses heat in the absence of oxygen to molecularly break down materials.

Q. Why do conventional methods of pyrolysis often use a catalyst?

A. Conventional methods of pyrolysis often use a catalyst because it speeds up the chemical reactions and achieves a high yield, but catalysts are very expensive and have a limited lifetime.

Q. What is the key to the new pyrolysis method developed by researchers?

A. The key is a 3D-printed electrically heated carbon column reactor made of three sections of decreasing pore size, which controls the reaction progress of the chemicals.

Q. How does the hierarchical porous structure in the reactor prevent larger molecules from advancing through it?

A. The hierarchical porous structure prevents larger molecules from advancing through the reactor before they have been adequately broken down.

Q. What is the temperature control mechanism in the reactor?

A. The temperature control mechanism in the reactor provides a way to control the temperature, which prevents coking and other effects that can inhibit the process.

Q. How much of the plastic waste was converted into chemicals for fuels in the test using the 3D-printed reactor?

A. The results reported a record-high yield of nearly 66% of the plastic waste converted into chemicals that can be used for fuels.

Q. What is the benefit of using 3D printing to build the structure of the reactor?

A. Using 3D printing allowed the researchers to precisely control the dimensions of the reactor pores and investigate the effects of pyrolysis.

Q. How did the device made up of commercially available carbon felt perform in comparison to the 3D-printed reactor?

A. The device made up of commercially available carbon felt still improved the selectivity of the pyrolysis products and achieved a satisfactory yield, converting more than 56% of the plastic into useful chemicals.

Q. What is the potential application of this system in real-world scenarios?

A. This system has great potential for putting it into real-world application and offering a practical strategy for converting plastic waste into valuable materials.

Q. Who are some of the additional collaborators involved in this research?

A. Additional collaborators include researchers from Purdue University, the University of Delaware, Missouri University of Science and Technology, West Virginia University, the University of Wisconsin–Madison, Princeton University, National Renewable Energy Laboratory, and BOTTLE Consortium.
